MixMatic M930
MixMatic - Mixing
6400166
Automatic compulsory mixer for coating mixtures, filler and glue.
The pivoting MixMatic M930 guarantees rapid homogeneous mixing of materials. Pivoting mixing arm and supplied special mixing containers ensure a smooth operation. That way unnecessary loss of material is avoided and the cleaning of the mixing tools in between is not necessary. As soon as the components to be mixed have been put in, the machine can be hydraulically lowered and brought into working position by pressing a button. During the mixing process additional components can be added.
At the end of the preselected mixing time the timer switches off the motor and the mixing machine goes back to its starting position. The mixing head will then be swung over to the next prepared mixing container.
All control elements are easy to use. Moving of the machine at the job site is very easy due to its rubber tires. The delivery of the machine includes two transport rollers and six mixing containers.
Technical information:
Mixer drive | Hydraulikaggregat |
---|---|
Drive | 2,5 kW (3,4 HP) / 3 ph. / 400 V / 50 Hz / 5 A
|
Electrical equipment | Splash-proof housing in compact electrical equipment; with reverser for choice of the turning direction and time switches for infinitely adjustable mixing time |
Performance | approx. 60 kg/2 min |
Weight | 180 kg |
Dimensions | L 1,050 x W 600 x H 1,000 mm |
Subject to technical changes
